High 12MP Resolution With Spotlight
This Power over Ethernet camera is ideal for adding to your Reolink NVR or use a PoE Switch and a MicroSD card.
Ultra Clarity with 12MP Ultra HD
With a F1.6 large aperture lens and 12MP (4512 x 2512 @ 20fps) ultra high definition, RLC-1212A allows you to enjoy flawless pictures and videos.
Smart Camera
Person/Vehicle & Pet detection with alerts direct to your phone.
Stunning Colour Night Vision
The powerful spotlight provide all the light you need to give clear, colour night vision.
Motion Zone
Customise the motion zone to your liking, decide where objects' movements will be detected and where they will not.
Multiple Storage Options
Save Videos to Micro SD Card, Reolink NVR or FTP server.
Time Lapse
Great for construction sites or for fun.
Perfect for NZ Condition
Rugged IP66 weatherproof rating.
Intruder Deterrence
Warn intruders with spotlight and sound alarm
Specifications
- Image Sensor: 1/2.49" CMOS Sensor
- Video Resolution: 4512 x 2512 (12 Megapixels) @ 20fps
- Lens: f=2.8mm, F=1.6, with IR cut
- Video Format:H.265
- Field of View: Horizontal: 118° Vertical: 66°
- IR-cut filter with auto-switching
- IR Night Vision: 30 meters (100 ft) (LED: 2pcs/28mil/850nm)
- Colour Night Vision: Spotlight 1pcs/4.3W/6500K/700 Lumens
- Audio: 2-way
- Power: PoE: IEEE 802.3af, 48V Active, DC Power: DC 12.0V ~ 1A, <12W
- Reset button
- Ethernet: One 10M/100Mbps RJ45
- Storage: Micro SD card slot (Max. 256GB)
- Audio: Built-in microphone
- Frame Rate: Mainstream: 2fps - 25fps (default: 25fps) Substream: 4fps - 15fps (default: 10fps)
- Code Rate: Mainstream: 1024Kbps -8192Kbps (default: 6144Kbps), Substream: 64Kbps - 512Kbps (default: 160Kbps)
- Browsers Supported: IE, Edge, Chrome, Firefox, Safari
- OS Supported: PC: Windows, Mac OS; Smartphone: iOS, Android
- Smart Alarm: Motion detection/Human detection/Vehicle detection
- Record Mode: Motion Record/Schedule Record (Default: Motion Record)
- Protocols & Standards: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
- Maximum User Access: 20 Users (1 admin account & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
- Work with: Google Assistant
- Operating temperature: -10°C~+55°C (14°F~131°F)
- Operating humidity: 10% ~ 90%
- Waterproof: IP66
- Size & Weight: Diameter 67mm x 187mm, 460g
